Heavy Duty Vertical High Speed Mixer for PVC Compound Production
Product Description
The SHR-500A Heavy Duty Vertical High Speed Mixer is developed for efficient hot mixing of PVC resin, fillers, stabilizers, lubricants, pigments, and other powder materials. The high-speed impeller creates strong friction, allowing materials to heat quickly while achieving excellent mixing uniformity.
Its robust structure ensures reliable operation during continuous production. The machine helps improve material dispersion, shorten processing time, and increase production efficiency. It operates as a standalone mixer or as part of a complete mixing line with automatic feeding, cooling, and conveying equipment.
The SHR-500A supports customized electrical standards, automation levels, and installation layouts. It provides a dependable solution for manufacturers seeking consistent product quality and long-term production stability.
Product Advantages
- High-speed friction heating for efficient material preparation
- Uniform powder blending with excellent dispersion
- Heavy-duty structure for continuous production
- Fast discharge and short production cycles
- Low maintenance and stable operation
- Compatible with automatic conveying and batching systems
- Customized solutions for different factory layouts
- OEM and ODM manufacturing supported
Technical Specifications
| Item |
Specification |
| Model |
SHR-500A |
| Total Volume |
500 L |
| Effective Volume |
375 L |
| Batch Capacity |
150-200 kg |
| Production Capacity |
600-800 kg/h |
| Main Motor Power |
55/75 kW |
| Mixing Speed |
430 / 860 rpm |
| Heating Method |
Friction Heating |
| Mixing Time |
8-12 min/batch |
| Discharge Type |
Pneumatic |
| Machine Weight |
3,600 kg |
| Overall Dimensions |
3050 × 2350 × 3150 mm |
| Contact Material |
SUS304 Stainless Steel |
| Voltage |
380V / 50Hz / Customized |
Reference Price
The SHR-500A is suitable for medium and large PVC compounding plants and plastic material processing factories.
FOB Shanghai Reference Price: USD 17,000 - 21,000 / Set
The final quotation depends on the machine configuration, automation level, electrical requirements, material selection, and optional equipment.
Application Industries
The SHR-500A is widely used in PVC flooring production, SPC flooring manufacturing, WPC products, PVC pipe extrusion, PVC profile production, cable compound processing, plastic recycling, masterbatch production, chemical powder blending, and construction material manufacturing. It delivers stable hot mixing performance for various industrial powder applications.
Applicable Materials
Suitable materials include PVC resin, calcium carbonate, talc powder, titanium dioxide, stabilizers, lubricants, pigments, fillers, recycled PVC powder, mineral powders, wood fiber, plastic additives, and other dry powder materials with good flowability.
Optional Configuration
Optional equipment includes touch-screen control, frequency speed regulation, automatic temperature control, vacuum feeding system, dust collection unit, cooling mixer connection, weighing and batching integration, storage hopper, material conveying system, and customized voltage or safety configurations.
Working Principle
The mixing blades rotate at high speed to create intensive friction between the materials and the inner wall of the mixing chamber. This process generates heat naturally while dispersing every ingredient evenly. After reaching the preset temperature or mixing time, the discharge valve opens automatically, and the mixed materials move to the cooling stage or the next production process.
Why Choose This Mixer?
The SHR-500A combines reliable mechanical performance with efficient mixing technology. Its durable design supports long production hours while maintaining stable mixing quality. The machine integrates easily into automated production lines and offers flexible customization for different manufacturing requirements.
Frequently Asked Questions
What is the production capacity of the SHR-500A?
The standard production capacity ranges from 600 to 800 kg/h, depending on the material formulation and production process.
Which materials can this mixer process?
The machine processes PVC resin, fillers, stabilizers, lubricants, pigments, recycled powder, mineral materials, and many other industrial powder materials.
Can the mixer connect with automatic production lines?
Yes. It connects with automatic feeding systems, cooling mixers, conveying equipment, weighing systems, and extrusion lines.
Can the machine be customized?
Yes. We provide OEM and ODM services, including customized capacities, control systems, electrical standards, machine colors, and factory layouts.
What optional equipment is available?
Customers can add automatic feeding, dust collection, cooling systems, weighing equipment, material conveying units, and other accessories according to production requirements.
